OEM Part Number | 7116-2876 |
---|---|
OEM Series | 58 Connector M Type |
MinMax Part Number | 1210000693 |
MinMax Family | MTU001 |
Tab Size (mm) | 6.3mm |
Male/Female | Female |
Sealable | No |
Wire Size (mm²) | 0.85-2.0mm2 |
Wire Size (AWG) | 18-14AWG |
Crimp Type | |
Material | Brass |
Interface Plating | Tin |
Load Current | 18(AWG)--6(A), 16(AWG)--6(A), 14(AWG)--16(A) |
Nominal Voltage Architecture (V) | 24,48 |
Operating Temperature Range | -40℃~120℃ |
Certification | ISO9001, RoHS, REACH, TS16949 |
